code quality

Gergő Pintér, PhD

gergo.pinter@uni-corvinus.hu

agile: working software over comprehensive documentation

software craftmanship: not only working software, but also well-crafted software

well-crafted

high quality
well-designed
validated and verified
tested
code is clean, easy to understand, maintain

code smell

a code smell is a surface indication that usually corresponds to a deeper problem

– Martin Flower [1]

software rot is the degradation, deterioration, or loss of the use or performance of software over time [2]

requirement smell: signs in the requirements that are not necessarily wrong but could be problematic [3]

clean clode violations as code smells

long method
long parameter list
naming
- notation in names
- inconsistent names
- uncommunicative names
comments
large class
- possibly do more than one thing
a function / class does more than one thing

source: [4]

some code smells

duplicated code
- Don’t Repeat Yourself! (a.k.a., DRY principle) [5]
speculative generality
- do not generalize the code to solve a potential future problem
- You aren’t gonna need it (YAGNI)
- focus on today’s problem
dead code
- e.g., a function that is never called
- editors denote it
- in Go unused variable is not a warning, but an error
temporary field
- “Watch out for objects that contain a lot of optional or unnecessary fields. If you’re passing an object as a parameter to a method, make sure that you’re using all of it and not cherry-picking single fields.” [4]

source: [4]

conditional complexity

if a and b:
    do_something()

if a or b:
    do_something()

if not (a or (b and not c) and (d or not f)):
    do_something()

hard to understand
even if it is tested and documented

conditional complexity

if is_pressure_low() and is_temperature_high():
    do_something()

if is_pressure_low() or is_temperature_high():
    do_something()

if not (
    is_pressure_low()
    or (is_temperature_high() and not is_humidity_low())
    and (is_fall() or not is_raining())
):
    do_something()

hard to understand, even if it is tested and documented
use nested conditions instead
avoid negative conditionals – Robert C. Martin [6]
- if (!is_raining()) {do_something();}

conditional complexity – use nested conditions

if not (
    is_pressure_low()
    or (is_temperature_high() and not is_humidity_low())
    and (is_fall() or not is_raining())
):
    do_something()

if not (
    is_pressure_low()
    or (is_temperature_high() and not is_humidity_low())
    and (is_fall() or not is_raining())
):
    do_something()

class-based smells: alternative classes with different interfaces

If two classes are similar on the inside, but different on the outside, perhaps they can be modified to share a common interface [4].

class-based smells: data class???

Avoid classes that passively store data. Classes should contain data and methods to operate on that data, too.

– Jeff Atwood [4]

comes from the OOP definition, but outdated

class-based smells: data clumps

If you always see the same data hanging around together, maybe it belongs together. Consider rolling the related data up into a larger class [4].

class-based smells: refused bequest

If you inherit from a class, but never use any of the inherited functionality, should you really be using inheritance? [4]

basically an architectural issue!

class-based smells: indecent exposure

Beware of classes that unnecessarily expose their internals. […] You should have a compelling reason for every item you make public. If you don’t, hide it [4].

OOP principle: abstraction

hiding the complex reality while exposing only the necessary parts
allows to focus on interactions at a higher level without needing to understand the details of the implementation
can be achieved through abstract classes and interfaces, which define a contract for what methods an object must implement without specifying how they should be implemented

class-based smells: feature envy

Methods that make extensive use of another class may belong in another class. Consider moving this method to the class it is so envious of.

– Jeff Atwood [4]

more code smells

this section is based on the book Clean Code (chapter 17) by Robert C. Martin [6]

with own examples

by Thomas Nast via Wikipedia public domain — by Thomas Nast via Wikipedia
public domain

comment related smells

1. obsolete comment

version n-1 (OOP)

# increase class attribute
def increase(self, by):
    self.foo += by

version n (FP)

# increase class attribute
def increase(what, by):
    return what + by

these are actually noise comments, so they are bad in the first place

comment related smells

3. commented-out code

def increase(what, by):
    # print(what, by)
    return what + by

not needed, just remove it

class Something:
    foo = 0

    def increase(self, by):
        self.foo += by

    def decrease(self, by):
        self.foo -= by

    # def mutiply(self, by):
    #     self.foo *= by

the version tracker will preserve it, if you might meed it sometime in the future

magic numbers

magic number is an unexplained constant in the code

def calculate_circle_area(r: float) -> float:
    return r * r * 3.141592

PI = 3.141592


def calculate_circle_area(r: float) -> float:
    return r * r * PI

import math


def calculate_circle_area(r: float) -> float:
    return r * r * math.pi

encapsulate boundary conditions

if level + 1 < length:
    do_somthing(foo, bar, level + 1)

next_level = level + 1
if next_level < length:
    do_somthing(foo, bar, next_level)

also increases consistency, the condition needs to be adjusted in one place

can be an adjustable parameter

denoting blocks

for (i = 0; i < 10; i++) {
    console.log(i);
}

for (i = 0; i < 10; i++)
    console.log(i);

var a = 0;
for (i = 0; i < 10; i++)
    a++;
    console.log(i);

for i in range(10):
    print(i)

a = 0
for i in range(10):
    a += 1
    print(i)

package main

import (
    "fmt"
)

func main() {
    for i:=0; i<10; i++ {
        fmt.Println(i)
    }
}

fn main() {
    for i in 0..9 {
        println!("{}", i);
    }
}

what could go wrong?

parts from sslKeyExchange.c

if ((err = ReadyHash(&SSLHashSHA1, &hashCtx)) != 0)
    goto fail;
if ((err = SSLHashSHA1.update(&hashCtx, &clientRandom)) != 0)
    goto fail;
if ((err = SSLHashSHA1.update(&hashCtx, &serverRandom)) != 0)
    goto fail;
if ((err = SSLHashSHA1.update(&hashCtx, &signedParams)) != 0)
    goto fail;
    goto fail;
if ((err = SSLHashSHA1.final(&hashCtx, &hashOut)) != 0)
    goto fail;

fail:
    SSLFreeBuffer(&signedHashes);
    SSLFreeBuffer(&hashCtx);
    return err;

more about Apple’s “goto fail” fiasco (2014): [7], [8]

false blame on goto, could be prevented by review and testing

how to measure code quality?

it is hard to objectively measure the quality of code

number of source lines of code (SLOC)
- more code, more (potential) issues
aligns well with code style guides
Halstead metrics
cyclomatic complexity
maintainability index
test coverage (later)

Halstead metrics

Halstead’s goal was to identify measurable properties of software, and the relations between them [9].

statistically computed numbers:

$\eta_1$ = the number of distinct operators
$\eta_2$ = the number of distinct operands
$N_1$ = the total number of operators
$N_2$ = the total number of operands

some of the measures:

program vocabulary: $\eta = \eta_1 + \eta_2$
program length: $N = N_1 + N_2$
calculated program length: $\widehat{N} = \eta_1 log_2{\eta_1} + \eta2 log_2{\eta_2}$
volume: $V = N log_2{\eta}$
difficulty: $D = \frac{\eta_1}{2} \cdot \frac{N_2}{\eta_2}$
effort: $E = D \cdot V$

cyclomatic comlexity

developed by Thomas J. McCabe in 1976
quantitative measure of the number of linearly independent paths through the source code
computed using the control-flow graph of the program

defined as:

$M = E - N + 2P$

E: the number of edges of the graph
N: the number of nodes of the graph
P: the number of connected components
- for a single method, P always equals 1

cyclomatic comlexity – example

def calculate_progress(
    finished: int,
    total: int,
    as_percentage: bool
) -> float:
    progress = finished / total

    if as_percentage:
        return progress * 100
    else:
        return progress

activity diagram

control flow

$CC = E - N + 2$ $CC = 4 - 4 + 2$ $CC = 2$

cyclomatic comlexity – 2nd example

def calculate_progress(
    finished: int,
    total: int,
    as_percentage: bool,
    foo: bool
) -> float:
    progress = finished / total

    if as_percentage and foo:
        return progress * 100
    else:
        return progress

activity diagram

control flow

$CC = E - N + 2$ $CC = 7 - 6 + 2$ $CC = 3$

Python statements’ effects on cyclomatic complexity

construct	effect	reasoning
if	+1	An if statement is a single decision.
elif	+1	The elif statement adds another decision.
else	+0	The else statement does not cause a new decision. The decision is at the if.
for	+1	There is a decision at the start of the loop.
while	+1	There is a decision at the while statement.
except	+1	Each except branch adds a new conditional path of execution.
finally	+0	The finally block is unconditionally executed.
with	+1	The with statement roughly corresponds to a try/except block.
boolean operator	+1	Every boolean operator (and, or) adds a decision point.

source: Radon documentation [9]

interpretation of cyclomatic complexity – Radon

CC score	rank	risk
1 - 5	A	low - simple block
6 - 10	B	low - well structured and stable block
11 - 20	C	moderate - slightly complex block
21 - 30	D	more than moderate - more complex block
31 - 40	E	high - complex block, alarming
41+	F	very high - error-prone, unstable block

source: Radon documentation [9]

maintainability index

original [10]:: $MI = 171 - 5.2 \ln{V} - 0.23G - 16.2\ln{L}$
Visual Studio derivate:: $MI = max\left[0,100 \frac{171 - 5.2 \ln{V} - 0.23G - 16.2\ln{L}}{171}\right]$

V: the Halstead volume
G: the total cyclomatic complexity
L: the number of source lines of code

Visual Studio
score	maintainability
0-10	low
10-20	moderate
20+	high

based on [11]
score	maintainability
0–10	low
10–20	moderate
20–30	good
30–40	very good
40–100	excellent

issues: ease of computation, language independence, understandability, explainability [12]

maintainability index – example

def calculate_progress(finished: int, total: int, as_percentage: bool) -> float:
    progress = finished / total

    if as_percentage:
        return progress * 100
    else:
        return progress


def calculate_progress_2(
    finished: int, total: int, as_percentage: bool, foo: bool
) -> float:
    progress = finished / total

    if as_percentage and foo:
        return progress * 100
    else:
        return progress

maintainability index for a script containing the code above is 63.71
calculated with Radon

go report

gofmt: style guide
go_vet: reports suspicious constructs (Go specific)
ineffassign: detects ineffectual assignments in Go code
gocyclo: cyclomatic complexity
license: checks whether your project has a LICENSE file
misspell: finds commonly misspelled English words

score	grade
>90
>80
>70
>60
>50
>40
<=40

Go Report Card for Gitea

code chunk permanence in a codebase

Linux codebase – from the Hercules (Git history analyser) documentation

there was no need to change it, presumably it was written well in the first place
multiple changes in a short period indicate problems during software development [14]

WTF per minute

references

[1]

M. Fowler, “Code smell.” https://martinfowler.com/bliki/CodeSmell.html , 09-Feb-2006.

[2]

Wikipedia contributors, “Software rot — Wikipedia, the free encyclopedia.” https://en.wikipedia.org/w/index.php?title=Software_rot&oldid=1236668404 , 2024.

[3]

H. Femmer, D. M. Fernández, S. Wagner, and S. Eder, “Rapid quality assurance with requirements smells,” Journal of Systems and Software, vol. 123, pp. 190–213, 2017.

[4]

J. Atwood, “Code smells.” https://blog.codinghorror.com/code-smells/ , 18-May-2006.

[5]

B. Venners, “Orthogonality and the DRY principle.” https://www.artima.com/articles/orthogonality-and-the-dry-principle , 10-Mar-2003.

[6]

R. C. Martin, Clean code: A handbook of agile software craftsmanship. Pearson Education, 2009.

[7]

D. A. Wheeler, “The apple goto fail vulnerability: Lessons learned.” https://dwheeler.com/essays/apple-goto-fail.html , 23-Nov-2014.

[8]

S. Migues, “Understanding the apple ‘goto fail;’ vulnerability.” https://www.blackduck.com/blog/understanding-apple-goto-fail-vulnerability-2.html , 25-Feb-2014.

[9]

Radon documentation, https://radon.readthedocs.io/en/latest/intro.html .

[10]

D. Coleman, D. Ash, B. Lowther, and P. Oman, “Using metrics to evaluate software system maintainability,” Computer, vol. 27, no. 8, pp. 44–49, 1994.

[11]

V. Sharma, “Analyzing software code — maintainability index.” https://mvineetsharma.medium.com/analyzing-software-code-maintainability-index-9765896c80f9 , 05-Feb-2024.

[12]

I. Heitlager, T. Kuipers, and J. Visser, “A practical model for measuring maintainability,” in 6th international conference on the quality of information and communications technology (QUATIC 2007), 2007, pp. 30–39.

[13]

A. van Deursen, “Think twice before using the ‘maintainability index’.” https://avandeursen.com/2014/08/29/think-twice-before-using-the-maintainability-index/ , 29-Aug-2014.

[14]

N. Nagappan, A. Zeller, T. Zimmermann, K. Herzig, and B. Murphy, “Change bursts as defect predictors,” in 2010 IEEE 21st international symposium on software reliability engineering, 2010, pp. 309–318.
